5052 H32 txhuas yog qhov muaj zog dua thiab muaj kev tiv thaiv corrosion zoo dua piv rau 3003 H14, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau cov chaw hauv dej hiav txwv thiab kev siv cov qauv hnyav. Ntawm qhov tod tes, 3003 H14 aluminium yog qhov tsim tau ntau dua thiab raug nqi - zoo, ua rau nws yog cov khoom siv dav dav rau kev tsim cov ntawv hlau, cov khoom siv sab hauv tsev, thiab cov haujlwm khoov txheem.
Tempers txhais li cas rau 3003 H14 Aluminium Sheet thiab 5052 H32?
Ua ntej sib piv cov hlau, koj yuav tsum nkag siab tias "H" temper codes txhais li cas, raws li lawv hais tias cov hlau yuav coj li cas ntawm koj lub Hoobkas hauv pem teb. Ob lub alloys tsis yog -kub- kho tau, txhais tau tias lawv lub zog los ntawm lub cev txias dov ntawm lub zeb.
- H14 Temper: Qhov "1" txhais tau tias nws yog strain-hardened (txias-rolled), thiab "4" txhais tau tias nws tau ua tiav rau ib nrab-Zoo mob. Nws muaj qhov sib npaug ntawm qhov nruab nrab lub zog thiab muaj peev xwm khoov zoo.
- H32 Temper: Qhov "3" txhais tau tias cov hlau raug strain- hardened thiab ces stabilized nrog qis-kub kub kho. Qhov "2" txhais tau tias nws tau ua tiav rau lub quarter-Zoo heev.
Tseem Ceeb Takeaway: Txawm hais tias H32 yog lej "quarter- nyuaj" npau taws thiab H14 yog "ib nrab- nyuaj" npau taws, 5052 H32 tseem muaj zog dua li 3003 H14 vim tias nws lub hauv paus chemistry (Al-Mg) yog ib txwm tougher.
Lub hauv paus ntawm Ob Cov Khoom Siv Txhuas Txhuas
3003 H14 Aluminium Phaj:
Qhov no yog Aluminium -Manganese (Al-Mn) alloy. Nws yog feem ntau siv dav dav - lub hom phiaj txhuas thoob ntiaj teb. Nws muaj kev ua haujlwm zoo, ua haujlwm zoo rau cov huab cua txheem, thiab lub zog nruab nrab.
5052 H32 Aluminium Phaj:
Qhov no yog Aluminium -Magnesium (Al-Mg) alloy. Cov magnesium hloov nws mus rau hauv siab - lub zog hlau. Qhov tseem ceeb tshaj, nws tau lees paub thoob ntiaj teb raws li "Marine Grade" alloy vim nws tuaj yeem muaj sia nyob tsis tu ncua raug dej ntsev.
Mechanical Properties ntawm 5052 H32 vs 3003 H14
| Khoom | 3003 H14 Aluminium | 5052 H32 Aluminium |
| Tensile zog | 145-215 MPa | 210-260 MPa |
| Yield zog | ~ 125 MPa | ~ 193-215 MPa |
| Elongation | 10% – 12% | 12% – 18% |
| Hardness (Brinell) | ~ 40 HB | ~ 60 HB |
| Qhov ntom | 2.73 g / cm³ | 2.68 g / cm³ |
| Thermal conductivity | ~ 180 – 193 W/m·K | ~ 138 W/m·K |
5052 H32 muaj zog heev. Nws lub zog tensile tuaj yeem yog 40% txog 70% siab dua 3003 H14. Nws lub zog tawm los (lub ntsiab lus uas cov hlau nyob ruaj khov khoov hauv qab qhov hnyav) yog ze li ob npaug ntawm 3003. Qhov no yog vim li cas 5052 yog siv rau kev thauj khoom -cov kabmob.
Corrosion Resistance ntawm Marine Qib 5052 H32 Aluminium Phaj
| Ib puag ncig | 3003 H14 Aluminium | 5052 H32 Aluminium |
| General Sab nraum zoov / Los nag | Zoo | Zoo heev |
| Marine Ib puag ncig | Nruab nrab | Zoo heev |
| Direct dej ntsev / ntsev tsuag | Limited (Yuav pit) | Muaj zog (Immune) |
Xaus:3003 H14 yog qhov zoo tshaj plaws rau cov qauv vaj tsev vov tsev thiab sab hauv tsev. Txawm li cas los xij, 5052 H32 yog qhov tsis muaj kev sib tw rau txhua yam uas kov dej hiav txwv, kev ntsev, lossis cov tshuaj lom neeg hnyav.
Kev sib sau thiab khoov 3003 H14 Aluminium vs 5052 H32
Koj cov nqi tsim khoom hnyav yog nyob ntawm seb cov ntaub ntawv no cuam tshuam li cas hauv koj lub xovxwm nres thiab lub tshuab stamping.
| Fabrication txheej txheem | 3003 H14 | 5052 H32 |
| Formability | Zoo heev | Zoo (yuav tsum muaj lub tshuab quab yuam ntau) |
| Kho tau yooj yim | Zoo heev (Folds yooj yim) | Zoo heev (muaj caij nplooj ntoos hlav-rov qab) |
| Weldability | Zoo heev | Zoo heev (Muab cov pob qij txha muaj zog) |
| Machinability (CNC) | Yooj yim | Medium (me ntsis gummy) |
Workshop Reality:3003 H14 khoov zoo li butter. Koj cov neeg ua haujlwm yuav nyiam nws vim nws tsis tshua tawg ntawm 90-degree fold. 5052 H32 yog tawv dua. Thaum koj khoov nws, nws yuav sim rov qab mus rau nws cov duab tiaj tus, txhais tau tias koj cov neeg ua haujlwm yuav tsum dhau-khoov nws.
Hom Kev Siv rau 3003 H14 thiab 5052 H32 Aluminium Panels
3003 H14 Daim Ntawv Thov
- Siv qhov no thaum koj xav tau pheej yig, txhim khu kev qha hlau uas yooj yim rau cov duab.
- Architecture: Kho kom zoo nkauj phab ntsa panels, vov tsev ntawv, thiab corrugated siding.
- Kev lag luam khoom noj khoom haus: Cookware, ci lauj kaub, thiab tub yees liner.
- HVAC: Cua txias ductwork thiab yeeb nkab rwb thaiv tsev jacketing.
- Siv dav dav: Cov paib txoj kev, daim ntawv tso cai, thiab cov thawv ntawv hlau.
5052 H32 daim ntawv thov
- Siv qhov no thaum muaj kev nyab xeeb, siab, thiab kev ncaj ncees ntawm cov qauv tseem ceeb.
- Marine: Nkoj hulls, pontoon decks, thiab nkoj kho vajtse.
- Kev Thauj Mus Los: Cov roj tank rau cov tsheb thauj khoom, tsheb thauj mus los, thiab lub tsheb npav.
- Cov Khoom Siv Khoom Siv: Cov hlab ntsha siab, hydraulic enclosures, thiab cov tshuab hnyav npog.
Xaiv 3003 H14 yog:Koj qhov project yuav tsum nruj bending, stamping, lossis kos duab sib sib zog nqus. Nws kuj yog qhov kev xaiv zoo tshaj plaws yog tias koj muaj kev nkag siab zoo rau cov nqi raw khoom thiab cov khoom tsis nqa hnyav.
Xaiv 5052 H32 yog:Koj tab tom tsim txhua yam uas nkag mus rau hauv dej hiav txwv. Nws tseem yuav tsum tau ua yog tias cov hlau yuav tsum tau ua raws li kev thauj khoom -cov qauv kabmob lossis lub siab - siab tank.
