Taw qhia rau Aluminium 1050 Phaj thiab Aluminium 1200 Phaj
Aluminium plays lub luag haujlwm tseem ceeb hauv ntau qhov kev lag luam ua tsaug rau nws lub teeb yuag, zoo corrosion kuj, thiab zoo heev hluav taws xob thiab thermal conductivity. Tsis pub dhau 1000 series ntawm aluminium alloys,Aluminium 1050 phajthiabAluminium 1200 phajyog ob qib siv dav, tshwj xeeb tshaj yog hauv cov ntawv thov uas xav tau siab purity thiab superior formability.
Txawm hais tias ob daim ntawv txhuas no muaj ntau qhov sib xws, lawv sib txawv hauv qib purity, conductivity, mechanical zog, thiab siv kawg siv. Nkag siab qhov sib txawv ntawm Aluminium 1050 thiab Aluminium 1200 txhuas daim hlau yog qhov tseem ceeb rau cov engineers, designers, thiab manufacturers aiming xaiv cov khoom haum rau kev ua tau zoo, nqi, thiab kav ntev.
Txheej txheem cej luam ntawm 1000 Series Aluminium Phaj
Lub 1000 series txhuas alloys raug cais raws li kev lag luam ntshiab txhuas, muaj tsawg kawg yog 99% txhuas. Alloys nyob rau hauv no series, suav nrog Aluminium 1050 phaj thiab Aluminium 1200 phaj, paub txog:
- Zoo heev corrosion kuj
- High hluav taws xob thiab thermal conductivity
- Zoo heev formability thiab weldability
Cov khoom no ua rau 1000 series txhuas daim hlau zoo tagnrho rau hluav taws xob, tshuaj lom neeg, vaj tsev, thiab khoom noj khoom haus- hais txog kev siv.
Tshuaj muaj pes tsawg leeg ntawm Aluminium 1050 Phaj vs Aluminium 1200 Phaj
Aluminium 1050 Phaj Chemical Composition
Aluminium 1050 txhuas phajmuaj qhov tsawg kawg nkaus ntawm 99.5% aluminium, ua rau nws yog ib qho ntawm cov qib siab tshaj plaws -purity coj mus muag txhuas qib. Cov ntsiab lus impurity yog nruj me ntsis txwv, uas ncaj qha mus rau nws superior conductivity.
Qhov ntau yam muaj pes tsawg leeg:
Silicon (Si): 0.25
Hlau (Fe): 0.40
Tooj liab (Cu): 0.05
Manganese (Mn): 0.05
Magnesium (Mg): 0.05
Zinc (Zn): 0.07
Lwm tus (txhua): 0.03
Lwm tus (tag nrho): 0.10
Aluminium 1200 Phaj Chemical Composition
Aluminium 1200 txhuas phajmuaj cov ntsiab lus tsawg tsawg ntawm aluminium me ntsis ntawm 99.0%. Nws tso cai rau qib siab ua ke ntawm silicon thiab hlau, uas cuam tshuam rau cov conductivity thaum me ntsis txhim kho lub zog.
Qhov ntau yam muaj pes tsawg leeg:
Silicon + Hlau (Si + Fe): 1.00
Tooj liab (Cu): 0.05
Manganese (Mn): 0.05
Magnesium (Mg): 0.05
Zinc (Zn): 0.10
Lwm tus (txhua): 0.05
Lwm tus (tag nrho): 0.15
Mechanical Properties ntawm Aluminium 1050 Phaj thiab Aluminium 1200 Phaj
Kev sib piv ntawm lub zog thiab hardness
Aluminium 1050 phajyog tus mos thiab tsis tshua muaj ductile. Nws lub zog tensile ib txwm nyob ntawm 45 txog 75 MPa, nrog rau Brinell hardness ntawm ib ncig ntawm 20 HB. Qhov no ua rau nws yooj yim rau khoov, daim ntawv, thiab sib sib zog nqus kos, tab sis txwv nws siv nyob rau hauv load-cov ntaub ntawv bearing.
Aluminium 1200 phajmuab me ntsis siab dua txhua yam lub zog vim nws cov ntsiab lus impurity. Nws lub zog tensile feem ntau yog li ntawm 50 txog 85 MPa, nrog rau Brinell hardness ntawm kwv yees li 22 HB, muab kev txhim kho me ntsis hauv kev nruj thaum tswj kev tsim tau zoo.
Conductivity Performance ntawm Aluminium 1050 Phaj vs Aluminium 1200 Phaj
Ua tsaug rau nws cov purity siab dua,Aluminium 1050 txhuas phajxa cov hluav taws xob zoo tshaj thiab thermal conductivity, feem ntau nyob ib ncig ntawm 61% IACS.
Aluminium 1200 txhuas phajtseem ua tau zoo nyob rau hauv conductivity- hais txog cov ntawv thov tab sis qis dua me ntsis, ntawm 59% IACS. Qhov sib txawv no tuaj yeem yog qhov tseem ceeb hauv cov ntawv thov uas yuav tsum muaj kev ua haujlwm siab tshaj plaws.
Formability, Weldability, thiab Corrosion Resistance ntawm Aluminium Phaj
Ob leeg Aluminium 1050 thiab Aluminium 1200 daim hlau muaj kev tsim tau zoo, ua rau lawv tsim nyog rau kev sib tw, khoov, dov, thiab sib sib zog nqus cov txheej txheem.
Aluminium 1050 phajyog tshwj xeeb tshaj yog haum rau cov duab complex vim nws softness thiab siab ductility.
Aluminium 1200 phajmuab qhov zoo sib npaug ntawm formability thiab lub zog.
Nyob rau hauv cov nqe lus ntawm corrosion kuj, ob daim hlau txhuas ua tau zoo heev vim yog ntuj oxide txheej ntawm qhov chaw. Txawm li cas los xij, nyob rau hauv ib puag ncig hnyav heev, Aluminium 1050 phaj tuaj yeem muab kev tiv thaiv me ntsis zoo dua vim tias nws cov purity ntau dua.
Cov ntawv thov ntawm Aluminium 1050 Phaj
Vim nws siab purity thiab conductivity,Aluminium 1050 txhuas phajfeem ntau yog siv rau hauv:
- Hluav taws xob conductors thiab busbars
- Thaum tshav kub kub exchangers thiab cua sov dab dej
- Cov khoom siv tshuaj ua haujlwm
- Cov thawv ntim khoom noj thiab ntim khoom
- Reflectors thiab cov teeb pom kev zoo
Kev lag luam feem ntau xaiv Aluminium 1050 phaj qhov twg conductivity, corrosion kuj, thiab yooj yim ntawm kev tsim yog qhov tseem ceeb.
Cov ntawv thov ntawm Aluminium 1200 Plate
Nrog nws cov kev sib xyaw ua ke ntawm zoo zog thiab formability,Aluminium 1200 txhuas phajyog dav siv nyob rau hauv:
- Kub exchangers thiab evaporators
- Architectural panels thiab lub tsev façades
- Cov cuab yeej siv tshuaj muaj zog
- Cov ntawv luam tawm
- Ru tsev, siding, thiab corrugated aluminium ntawv
Aluminium 1050 Phaj vs. Aluminium 1200 Phaj: Performance Comparison Table
| Khoom | Aluminium 1050 Phaj | Aluminium 1200 Phaj |
|---|---|---|
| Yam tsawg kawg ntawm Aluminium | Ntau dua lossis sib npaug li 99.5% | Ntau dua lossis sib npaug li 99.0% |
| Tensile zog (MPa) | 45–75 | 50–85 |
| Hluav taws xob conductivity | ~ 61% IAB | ~ 59% IAB |
| Brinell Hardness (HB) | ~20 | ~22 |
| Formability | Zoo heev | Zoo heev |
| Corrosion Resistance | Zoo heev | Zoo heev |
| Tej kev siv | Hluav taws xob, thermal, zaub mov, tshuaj | Architectural, industrial, hloov tshav kub |
Tus nqi thiab muaj ntawm Aluminium 1050 Phaj thiab Aluminium 1200 Phaj
Los ntawm kev xav txog nyiaj txiag,Aluminium 1050 phajfeem ntau yog me ntsis kim dua vim nws cov purity siab dua.Aluminium 1200 phajmuab tus nqi - lwm txoj kev zoo thaum qhov kev ua tau zoo qis dua yog qhov lees txais.
Ob lub phaj txhuas yog dav muaj nyob rau hauv nplooj ntawv, daim hlau, coils, thiab foils thiab tuaj yeem muab nkag rau hauv ntau yam kev kub ntxhov kom haum rau kev xav tau sib txawv.
Xaus: Xaiv Qhov Nruab NrabAluminium 1050 Phajthiab Aluminium 1200 Phaj
Hauv cov ntsiab lus, qhov sib txawv ntawm Aluminium 1050 thiab Aluminium 1200 txhuas daim hlau yog nyob rau hauv purity, conductivity, thiab mechanical zog. Aluminium 1050 phaj excels nyob rau hauv daim ntawv thov qhov siab tshaj plaws hluav taws xob thiab thermal conductivity yog yuav tsum tau, thaum Aluminium 1200 phaj muaj ib tug sib npaug tov nrog me ntsis siab zog thiab zoo formability.
Qhov kev xaiv kawg yuav tsum yog raws li cov kev xav tau ntawm daim ntawv thov, kev cia siab rau kev ua tau zoo, thiab kev xav txog nyiaj txiag.
Txhawm rau txhim khu kev qha, siab - zoo Aluminium 1050 phaj lossis Aluminium 1200 phaj, hu rauGNEEhnub no thiab cia peb pab neeg ua haujlwm pab txhawb koj qhov project nrog cov ntaub ntawv muaj txiaj ntsig thiab kev pabcuam tshaj lij.
