5052 txhuas ntawv yog ib qho nrov uas tsis yog- cua sov- kho tau aluminium alloy uas muaj corrosion kuj, weldability, thiab nruab nrab lub zog. Raws li ib tug tswv cuab ntawm AL-Mg series alloy aluminium ntawv, nws yog cov khoom siv zoo tshaj plaws rau marine, automotive, thiab cov ntawv thov kev lag luam uas yuav tsum tau ua kom tawv thiab formability. GNEE wholesales tag nrho - loj 5052 txhuas daim hlau thiab muaj kev txiav, txiav, pleev xim, thiab lwm yam kev pabcuam, nrog rau cov kev daws teeb meem. Yog tias koj txaus siab, thov hu rau peb kom paub ntxiv.
5052 txhuas ntawv Specification
| Yam khoom | 5052 aluminium ntawv |
| Qhov Chaw Keeb Kwm | HENAN, Suav teb |
| Kub |
F, O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, H114, thiab lwm yam. |
| Lub sij hawm xa tuaj | 15-28 hnub |
| Qib | 5052 |
| Xim | Nyiaj |
| Kev Pabcuam | Punching, Txiav, Slitting, Painting, Embossing, Pattern printing |
|
Thickness (mm) |
1.0-600 |
|
Dav (mm) |
100-2650 |
|
Ntev (mm) |
500-16000 |
| Txuj | ASTM, AISI, JIS, DIN, GB |
| MOQ | 5 ton |
| Lub sijhawm them nyiaj | 30% TT ua ntej + 70% tshuav nyiaj li cas |
| Qauv | Dawb |
| Yam khoom | FOB, CIF, EXW, thiab lwm yam. |
| Ntim | Txheem Hiav Txwv- tsim nyog ntim |
| Daim ntawv pov thawj | ISO 9001, SGS, ABS, BV |
Kev xaiv kho saum npoo
Txhawm rau txhim kho kev ua haujlwm ntev thiab kev ntxim nyiam, 5052 txhuas ntawv tuaj yeem ua raws li hauv qab no:
Mill Finish: Aluminium liab qab, tus nqi- zoo thiab zoo tagnrho rau kev siv hauv kev lag luam. Nws tuaj yeem siv rau ob qho tib si ntau lawm thiab rov ua dua tshiab.
Anodizing: Ua kom corrosion kuj thiab tuaj yeem ua xim.
Painting: Muab khawb tiv thaiv thiab xim tiav; Cov xim xim yog xaiv tau, thiab xim yog raws li Ral xim daim ntawv.
Txhuam / Satin: Kho kom zoo nkauj thiab tiv thaiv- glare nto.
Embossing: Ntxiv cov qauv kev ntxhib los mos (pob zeb diamond thiab stucco), uas tuaj yeem hloov kho.
Ntsiab nta
Zoo heev corrosion kuj:
5052 aluminium alloy phaj yog corrosion{1}} cov khoom siv tiv taus uas ua tau zoo nyob rau hauv qhov chaw ntub dej. Nws tsis yooj yim cuam tshuam los ntawm oxidation lossis corrosion thaum lub sij hawm ntev - siv thiab tuaj yeem ua haujlwm tau zoo hauv ob qho tib si kua thiab gaseous media.
Lub zog nruab nrab:
Nws lub zog tensile yog li ntawm 170 MPa rau 270 MPa nyob ntawm qhov kub ntawm cov hlau. Lub zog no ua tau raws li cov kev xav tau dav dav hauv kev lag luam yam tsis muaj kev ua haujlwm nyuaj vim qhov nyuaj heev.
Kev ua haujlwm txias txias zoo:
Cov hlau tuaj yeem ua rau ntau hom thiab ntau thiab tsawg los ntawm kev sib tsoo, dov, ncab, thiab lwm yam txheej txheem. Nws kuj muaj qhov kub zoo - ua haujlwm plasticity.
Weldability zoo heev:
5052 txhuas ua tau zoo nyob rau hauv cov roj vuam, arc vuam, tsis kam vuam, chaw vuam, thiab seam vuam. Cov pob qij txha welded tuav lub zog siab thiab yas, nrog lub zog vuam ncav cuag 90% -95% ntawm lub hauv paus hlau.
Machinability thiab polishability:
Txawm hais tias qhov kev ua tau zoo hauv lub xeev annealed tsis yog qhov zoo tagnrho, nws tseem txhim kho hauv qhov txias - mob hnyav. Cov khoom siv kuj yog polishable heev, ua kom ci, glossy nto tom qab polishing.
Tshuaj thiab lub cev muaj zog
Tshuaj muaj pes tsawg leeg
| Element | Cov ntsiab lus (%) |
| Aluminium (Al) | Tshuav |
| Magnesium (Mg) | 2.2–2.8 |
| Chromium (Cr) | 0.15–0.35 |
| Hlau (Fe) | Tsawg dua lossis sib npaug li 0.40 |
| Silicon (Si) | Tsawg dua lossis sib npaug li 0.25 |
| Copper (Cu) | Tsawg dua lossis sib npaug li 0.10 |
| Manganese (Mn) | Tsawg dua lossis sib npaug li 0.10 |
Mechanical Properties
| Khoom | Tus nqi |
| Tensile zog | 193-228 MPa (28-33 ksi) |
| Yield zog | 90-190 MPa (13-28 ksi) |
| Elongation | 12–25% |
| Hardness (Brinell) | 60-80 HB |
| Qhov ntom | 2.68 g / cm³ |
Cov cheeb tsam thov
Tsheb:
Siv rau lub qhov rooj, hoods, nruab nrab console trims, sab hauv panels, thiab lub hau hau. Nws lub teeb yuag pab txo lub cev hnyav ntawm lub tsheb, thaum nws lub zog nruab nrab ua kom muaj kev nyab xeeb ntawm cov qauv. Tsis tas li ntawd, nws polishability muab lub ci ntsa iab thiab pom kev zoo nkauj tiav.
Roj tank:
Cov alloy tsis tsuas yog muab kev tiv thaiv zoo rau roj corrosion tab sis kuj txhim kho qhov chaw siv thiab kev nyab xeeb ntawm lub tank qauv. Niaj hnub no, ntau dua 80% ntawm hnyav- tsheb thauj khoom roj tank kev lag luam siv txhuas alloy roj tank.
Curtain phab ntsa & qhov rooj / qhov rai:
Nws muaj ntau yam xim xaiv thiab gloss ntau ntau, muaj zog cua tsis kam, thiab txhim khu kev qha kev nyab xeeb nyob rau hauv ib puag ncig hnyav. Nws tuaj yeem tsim rau hauv qhov rais thav duab, sashes, thiab lwm yam.
Qab nthab thiab kho kom zoo nkauj:
Hauv cov tsev lag luam, chaw ua haujlwm, tsev kho mob, thiab cov chaw zoo sib xws, 5052 aluminium ceilings ntsib hluav taws kub- tiv taus thiab ya raws- tiv taus. Nws cov ces kaum huv si thiab cov kab nkhaus ntxiv qhov pom kev zoo nkauj rau sab hauv tsim.
Electronic khoom vaj tse:
Siv rau hauv cov xov tooj ntawm tes, ntsiav tshuaj, thiab laptops. Nws muab kev tiv thaiv ruaj khov rau cov khoom siv hluav taws xob sab hauv, thaum kho qhov chaw xws li anodizing thiab sandblasting ntxiv cov cim zoo nkauj thiab kev zoo nkauj.
Nkoj:
Siv rau decks, sab panels, cabin partitions, sab hauv, thiab lwm yam nkoj. Nws zoo tiv thaiv dej hiav txwv corrosion, ncua lub nkoj kev pab cuam lub neej, thiab txo qhov hnyav tag nrho.
Kho vajtse:
Haum rau tes tuav, hinges, xauv, muaj automation khoom vaj tse, thiab lwm yam. Nws cov kev ua tau zoo ua tau zoo tso cai rau cov khoom siv kho vajtse kom ua tiav qhov zoo nkauj thiab txhim khu kev qha.
Kev thauj mus los:
Siv rau txoj kev teeb pom kev zoo, cov paib tsheb, thiab lwm yam khoom siv sab nraum zoov. Nws ua tau zoo nyob rau hauv ntev - siv sab nraum zoov ua tsaug rau nws cov huab cua muaj zog tiv thaiv thiab cov khoom muaj kev cuam tshuam.
Kev siv cov Thickness sib txawv
Nyias phaj (0.15-3mm):
Feem ntau siv hauv cov khoom siv hluav taws xob hauv tsev, LCD back panels, keyboards, thiab cov ntawv siv zoo sib xws. Cov phaj nruab nrab ntawm 0.5 thiab 1 hli yog dav siv hauv xov tooj ntawm tes thiab ntsiav tshuaj casings, muab ob qho tib si lub teeb yuag thiab txaus lub zog thiab cua sov dissipation.
Medium phaj (3-20 mm):
Feem ntau siv nyob rau hauv automotive manufacturing thiab mechanical processing. Daim hlau nyob rau hauv 3-5 hli ntau yam yog ib yam rau automotive engine txheej vaj huam sib luag, lub tsheb lub nra compartment vaj huam sib luag, thiab lwm yam Cheebtsam uas yuav tsum tau muaj zog structural thiab txo qhov hnyav.
Thick plate (>20 hli):
Siv nyob rau hauv kev tsim pwm, silos, cia tank, thiab lwm yam hnyav - daim ntawv thov. Hauv pwm ntau lawm, 5052 txhuas daim hlau nrog tuab ntawm 50-100 hli tuaj yeem siv los ua cov qauv rau pwm loj, muab lub zog txaus thiab ruaj khov.
5052 vs. Lwm yam Aluminium Alloys
| Alloy | Lub zog | Corrosion Resistance | Weldability | Zoo tshaj rau |
| 5052 | Nruab nrab | Zoo heev | Zoo heev | Marine, automotive, sheet hlau ua haujlwm |
| 3003 | Tsawg | Zoo | Zoo heev | Kev ntim khoom noj, khoom siv tshuaj |
| 6061 | Siab | Zoo | Zoo (yuav tsum tau tom qab-weld kho cua sov) | Cov qauv, aerospace, siab - qhov kev ntxhov siab |
| 5083 | Siab heev | Zoo heev | Zoo | Shipbuilding, kev siv tub rog |
Ua ke cov lus saum toj no, 5052 muaj kev tiv thaiv corrosion zoo dua li 6061, muaj zog dua thiab yooj yim rau kev tsim dua 3003, thiab tus nqi ntau dua - zoo dua 5083 rau kev siv dav dav.
