1100 O H14 H18 H112 Aerospace Aluminium Tube Cov lus piav qhia
Ntau tus neeg yuav khoom yuam kev ntseeg tias txhua "aerospace aluminium" yuav tsum yog ultra- cov ntaub ntawv muaj zog, nruj zoo li 7000 lossis 2000 series. Tab sis nyob rau hauv tiag tiag - ntiaj teb no aircraft tsim, tsis yog txhua feem tuav lub luj ntawm tis. Yuav ua li cas txog cov kab qis - cov kua dej siab? Internal HVAC ducting? Lub tshav kub exchangers?
Rau cov ntawv thov no, engineers tsis xav tau lub zog loj heev -lawv xav tau kev huv huv huv, zoo meej formability, thiab tsis muaj kev pheej hmoo ntawm corrosion. Qhov no yog raws nraim qhov peb AA1100 txhuas raj thiab yeeb nkab tuaj.
AA1100 yog kev lag luam ntshiab txhuas (Ntau dua lossis sib npaug rau 99.0% purity). Nws yog mos heev, muaj zog heev, thiab tiv thaiv tag nrho rau feem ntau corrosive ib puag ncig.
Tshuaj muaj pes tsawg leeg ntawm 1100 Aluminium Tubing
Yog vim li cas qhov no alloy ua tau zoo heev nyob rau hauv ib puag ncig corrosive yog nws tsis muaj cov ntsiab lus tseem ceeb alloying. Nws yog qhov tseem ceeb ntshiab hlau.
| Element | Cov ntsiab lus (%) | Nws txhais li cas rau cov neeg yuav khoom |
| Aluminium (Al) | Ntau dua lossis sib npaug li 99.00 | Muab superior corrosion kuj thiab siab hluav taws xob / thermal conductivity. |
| Copper (Cu) | 0.05 – 0.20 | Ntxiv rau me me kom me ntsis txhim kho kev ua haujlwm tsis muaj kev txi purity. |
| Hlau + Silicon (Fe + Si) | Tsawg dua lossis sib npaug li 1.00 | Ib txwm tshwm sim impurities uas yog nruj me ntsis tswj kom cov hlau mos mos, ductile xwm. |
| Zinc (Zn) | Tsawg dua lossis sib npaug li 0.10 | Capped ntawm qib qis heev los tiv thaiv teeb meem galvanic corrosion. |
| Manganese (Mn) | Tsawg dua los yog sib npaug li 0.05 | Khaws mus rau qhov tsawg kawg nkaus kom ntseeg tau tias cov alloy tseem muaj qhov tsim tau zoo heev. |
Mechanical Properties ntawm 1100 Seamless Yeeb Nkab
Vim tias 1100 yog cov ntshiab txhuas, nws tsis tuaj yeem hardened los ntawm kev kho cua sov. Factories siv "kev ua haujlwm txias" (xws li dov lossis kos duab) los ua kom nws lub zog. Ntawm no yog yuav ua li cas cov cuab yeej kho tshuab hloov pauv raws li tus npau taws koj xaiv.
| Kub | Tensile zog (MPa) | Yield zog (MPa) | Elongation (%) | Qhov xwm txheej |
| 1100-O | 70 – 95 | 20 – 35 | Ntau dua lossis sib npaug li 25% | Fully Annealed (Softest) |
| 1100-H14 | 90 – 110 | 35 – 50 | Ntau dua lossis sib npaug li 10% | Ib nrab -Hard |
| 1100-H18 | 110 – 130 | 75 – 95 | Tsawg | Puv -Nruab |
| 1100-H112 | ~ 90 | ~ 30 | Nruab nrab | Raws li -Fabricated |
Yuav ua li cas nyeem cov ntaub ntawv no:Daim ntawv ceeb toom tsawg npaum li cas lub zog tawm los ntawm "O" temper yog (tsuas yog 20-35 MPa). Qhov no txhais tau tias koj tuaj yeem khoov tau yooj yim 1100-O raj nrog koj txhais tes. Nws yog nruj me ntsis rau cov khoom uas tsis yog-loading.
Cov yam ntxwv tseem ceeb ntawm 1100 Extruded Aluminium Tube
- Extreme Corrosion Resistance:Cov ntshiab aluminium instantly tsim ib txheej tiv thaiv oxide. Nws yuav tsis xeb los yog degrade txawm thaum raug hnyav aviation fuels, lubricants, los yog huab cua.
- Unmatched Formability:Nws tuaj yeem spun, sib sib zog nqus- kos, thiab khoov rau hauv cov coils nruj heev yam tsis muaj kev tawg.
- Zoo heev thermal conductivity:Zoo meej rau kev hloov cua sov tawm ntawm cov tshuab dav hlau tseem ceeb.
- High Electrical Conductivity:Feem ntau siv los tiv thaiv kev tiv thaiv rau cov hluav taws xob hnyav hauv lub fuselage.
- Yooj yim Weldability:Nws tuaj yeem txuas tau sai thiab nyab xeeb siv cov txheej txheem TIG lossis MIG yam tsis muaj kev sib koom ua ke.
Aerospace Applications rau AA1100 Txhuas Yeeb Nkab
Txoj Cai Tseem Ceeb Engineering:Tsis txhob siv AA1100 rau cov qauv thav duab, tsaws iav, lossis siab -siab hydraulics. Nws yuav ua tsis tau raws li qhov hnyav hnyav.
Txawm li cas los xij, nws yog cov khoom siv zoo tshaj plaws rau kev siv aerospace thiab aviation hauv qab no:
- Tsawg- Roj thiab Roj Kab:Hloov cov kua dej nyob hauv qhov chaw siab tsawg tab sis corrosion kuj yuav tsum yog 100%.
- Kub Exchangers thiab Radiators:Khoov rau hauv nruj coils los tswj cov cua txias lossis cua txias hauv cov dav hlau ua lag luam.
- HVAC kav dej:Siv nyob rau hauv ib puag ncig tswj systems (ECS) los coj cov huab cua hauv tsev. Qhov xwm txheej hnyav pab txo tag nrho cov dav hlau hnyav.
- Rwb thaiv tsev Jacketing:Ua raws li kev tiv thaiv, tsis yog - lub tsho sab nrauv rau cov khoom siv hluav taws xob.
- Tsis yog-Load-Cov Kabmob Cabin Cheebtsam:Kho kom zoo nkauj trims, lub teeb yuag galley (chav ua noj) khoom siv, thiab cov kab dej hauv chav dej.
Specifications rau AA1100 Aluminium Yeeb Nkab
| Alloy | 1100 |
| Kub | O H14 H18 H112 |
| Aluminium tube sab nraud txoj kab uas hla | 2-1000 hli |
| Phab ntsa thickness | 0.5-50 hli |
| Txuj | GB∕T 33230-2016, ASTM B241, ASTM B221, |
| Kev tsim khoom | Kub extrusion, seamless extrusion, thiab txias drawn tube xaiv muaj. |
Puas yog koj tsim cov kab hloov pauv dej tab sis tsis paub tseeb tias 1100 txhuas tuaj yeem tswj koj lub siab sab hauv? Tsis txhob twv. Xa koj daim duab CAD lossis kev ua haujlwm siab rau GNEE. Peb pab pawg kws tshaj lij yuav suav cov kev ntxhov siab thiab pom zoo seb koj puas xav tau 1100-O, 1100-H14, lossis muaj zog alloy zoo li 5052-tsis muaj nqi rau koj.
Siv cov lus qhia yooj yim no ua ntej koj yuav:
| Yog koj order... | Xaiv qhov Temper no | Vim li cas? |
| Rau nruj dabtsi yog khoov, coiling, los yog flaring | 1100-O | Nws yog tag nrho annealed. Nws yuav khoov tau yooj yim yam tsis muaj qhov tawg ntawm lub voj voog sab nraud. |
| Rau general fabrication thiab lub teeb machining | 1100-H14 | Ib nrab- nyuaj muab qhov nruj txaus kom cov yeeb nkab ua kom nws cov duab ncaj nraim, tab sis tseem tuaj yeem siv khoov maj mam. |
| Rau cov kab ncaj nraim uas xav tau siab tshaj plaws | 1100-H18 | Tag nrho - nyuaj. Tsis txhob sim khoov qhov no. Nws yog siv thaum cov yeeb nkab yuav tsum nyob twj ywm nruj. |
| Rau qhov yooj yim industrial kav ncaj nraim los ntawm extruder | 1100-H112 | Raws li -fabricated. Tus nqi - ua tau zoo thaum koj tsis xav tau cov khoom siv kho tshuab zoo heev. |
Vim li cas thiaj xaiv GNEE ua koj 1100 Tube Supplier?
- 100% Cov ntaub ntawv pov thawj: Txhua pawg ntawm ASTM B241 1100 txhuas yeeb nkab tuaj nrog daim ntawv pov thawj Mill Test (MTC), ua pov thawj nws cov tshuaj muaj pes tsawg leeg thiab kev ua haujlwm zoo.
- Tag Nrho Cov Yeeb Nkab & Tube: Txawm hais tias koj xav tau ib lub raj extruded los yog precision 1100 aluminium txias-kos raj, peb tsim nws.
- Customization Experts: Peb tsis yog muag cov khoom lag luam xwb. Peb txiav kom ntev, kho cov phab ntsa thicknesses, thiab muab cov tempers tshwj xeeb raws li koj cov kev xav tau tiag tiag engineering.
- Ntiaj teb Export Experience: Los ntawm hiav txwv zoo-freight ntim (tiv thaiv dawb xeb thiab kev puas tsuaj) los tuav cov ntaub ntawv kev lis kev cai nyuaj, peb xyuas kom meej tias koj cov khoom tuaj txog yam xyuam xim, nyob qhov twg hauv lub ntiaj teb no.
- Kev xa khoom sai: Nrog rau cov khoom siv raw khoom loj thiab cov kab ntau lawm, peb muab qee lub sij hawm luv tshaj plaws hauv kev lag luam rau kev txiav txim.
Npaj rau qhov kev txiav txim lossis kos cov nqi hnub no?
Tau txais ncaj qha Hoobkas nqi ntawm tag nrho cov kev cai 1100-O extruded yeeb nkab thiab 1100-H14 seamless txhuas tubing.
Thov koj daim ntawv pov thawj Mill Test dawb (MTC) qauv.
Flexible MOQ (Yam tsawg kawg nkaus Order Quantity) rau kev sim khiav.
Xa peb koj qhov ntau thiab tsawg, thiab peb cov kws tsim khoom muag yuav muab cov lus qhia ntxaws hauv 24 teev.
Tau txais cov lus hais hauv 24 teev
