6063 Aluminium Pipe Description
Aluminium alloy 6063yog ib qho ntawm feem ntau siv alloys nyob rau hauv 6000 series, muaj nuj nqis rau nws extrudability zoo heev thiab superior nto zoo. Thaum tshav kub kho, 6063 txhuas ua rau pom muaj zog tiv thaiv corrosion, nrog rau kev txhim khu kev qha rau kev ntxhov siab corrosion tawg. Nws tuaj yeem yooj yim welded lossis brazed siv cov txheej txheem kev lag luam, ua rau nws tsim nyog rau ntau yam txheej txheem fabrication.
NtawmGNEE, Aluminium Alloy 6063 feem ntau nkag rau hauvT5, T52, thiab T6 tempers, tshwj xeeb tshaj yog rau kev siv hluav taws xob uas yuav tsum muaj hluav taws xob zoo. Cov alloy no kuj teb tau zoo heev rau anodizing. Tempers xws liT5, T52, T53 (matte tiav), T54, thiab T6 (lustrous tiav)xa cov xim tsis sib xws, kev ntxhib los mos, thiab ua kom pom kev pom zoo tom qab kho qhov chaw.
Kev siv tseem ceeb thiab kev siv ntawm 6063 Aluminium Alloy
Architectural thiab tsev systems
Aluminium extrusion
Qhov rai thiab qhov rooj ncej
Lub khw fittings thiab cov qauv qhia
Cov kav dej thiab cov kav dej
Railings thiab aluminium rooj tog
6063-T6 aluminium yeeb nkab, muab los ntawmGNEE, yog ib qho khoom siv extruded dav siv nyob rau hauv daim ntawv thov qhov chaw zoo li qhov tseem ceeb. Nws yog tshwj xeeb tshaj yog haum rau fabrication tej yaam num uas yuav tsum tau lub teeb yuag qauv ua ke nrog zoo heev corrosion kuj thiab ntev kev pab cuam lub neej.
Raws li tus kws tshaj lij aluminium tsum,GNEEmuab siab -zoo 6063 txhuas cov khoom nrog kev ua haujlwm ruaj khov, qhov ntev ntev, thiab ua kom zoo ib yam kom tau raws li kev xav tau ntawm kev tsim vaj tsev, kev lag luam, thiab hluav taws xob thov.
6063 aluminium yeeb nkab zoo li
6063 Aluminium Tube Specifications
| Qib | 6061/6063/6082/6060 |
| Kub | O/T4/T5/T6/T651/H112/H32 |
| OD Ntau | 1/8 "- 16" (3mm-2500mm) |
| Thickness | TXC 20 SCH 30 SCH 40 STD SCH 80 SCH 60 SCH 80 SCH 120 SCH 140 SCH 160 XXS |
| Daim ntawv | Round, Square, Rectangular, Custom, Hollow, Extruded Yeeb Nkab, thiab lwm yam |
| Hom | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Xaus | Plain End, Beveled kawg, Threaded |
CHEMICAL COMPOSITION |
|
| Element | Feem pua |
| Al | 98.9 |
| Cr | 0.1 max |
| Cu | 0.1 max |
| Mg | 0.45 - 0.9 |
| Fe | 0.35 max |
| Mn | 0.1 max |
| Si | 0.2 - 0.6 |
| Zn | 0.1 max |
| Ti | 0.1 max |
MECHANICAL INFORMATION |
||
| Imperial | Metric | |
| Qhov ntom | 0.1 lb / hauv 3 | 2.7 g / cc |
| Qhov kawg Tensile Strength | 27,000 psi | 186 MPa rau |
| Yield Tensile zog | 21,000 psi | 145 MPa |
| Kev qaug zog | 10,000 psi | 68.9MPa ua |
| Shear Strength | 17,000 psi | 117 MPa |
| Melting Point | 1, 140 - 1, 210℃F | 616 - 654 degree |
| Kub | T52 |
| Hardness Knoop | 83 |
| Hardness Brinell | 60 |
GNEE 6063 Cov Khoom Siv Txhuas
Txog Peb
Kev Pabcuam Ua Haujlwm muab los ntawm GNEE
NtawmGNEE, peb muab ntau yam kev pabcuam txhuas ua tiav los txhawb cov haujlwm tsim kho, kev ua siab ntev ntev, thiab kev xa khoom sai thoob plaws ntau qhov kev lag luam.
Precision txiav cov kev pab cuam
Peb muab cov raj laser txiav, daim ntawv laser txiav, siab -txhais ntshav txiav, thiab waterjet txiav kom ua tiav cov npoo huv, qhov tseeb siab, thiab tswj qhov ntev.
CNC machining peev xwm
Cov txheej txheem CNC Advanced xws li drilling, milling, tapping, threading, thiab kawg - kev tsim muaj kom tau raws li cov neeg siv khoom kos duab kos duab thiab cov kev cai nruj heev.
Khoov thiab tsim kev daws teeb meem
GNEE specializes nyob rau hauv kev cai dabtsi yog khoov thiab tsim ntawm 6063 txhuas round tubes, square tubes, thiab rectangular raj, nrog rau telescopic raj sib dhos thiab complex profiles.
Kev cai aluminium extrusion profiles
Peb txhawb OEM kev tsim khoom thiab tus kws txiav plaub hau- ua txhuas extrusion raws li CAD cov duab kos, cov qauv, lossis cov qauv kev lag luam, kom ntseeg tau qhov profile geometry thiab kev ua tau zoo.
Kev pabcuam vuam thiab fabrication
Kev cob qha TIG thiab MIG vuam, thav duab sib dhos, thiab cov khoom tsim khoom yog muab rau ob qho tib si kev lag luam khoom siv thiab kev tsim vaj tsev aluminium.
Nto xov xaiv
Muaj ntau yam kev kho mob saum npoo av, suav nrog anodizing (ntshiab, dub, bronze, thiab xim), polishing, thiab hmoov txheej los txhim kho corrosion thiab txhim khu kev pom kev pom.
Kev xa khoom sai thiab txhim khu kev qha
Los ntawm kev sib txuas ua ke npaj ua ntej-rau- nkoj cov khoom lag luam txhuas nrog rau hauv- kev ua haujlwm hauv tsev, GNEE ua kom lub sijhawm hloov pauv sai rau cov qauv qauv, cov khoom me me, thiab loj - ntim xaj.
