1050 Aluminium Sheet & Phaj - Pure Aluminium Solution rau Kev Lag Luam Kev Lag Luam
Nrhiav rau tus nqi-cov ntawv ntshiab txhuas zoo nrog kev tsim tau zoo thiab kev tiv thaiv corrosion?
GNEE 1050 Aluminium Sheet thiab Phajxa cov khoom ruaj khov, tus nqi sib tw, thiab kev siv dav hauv kev lag luam, ua rau lawv yog ib qho ntawm feem ntau siv cov qib txhuas hauv cov khoom lag luam zoo thoob ntiaj teb.
1050 Aluminium Sheet Txheej txheem cej luam - Pure Aluminium Phaj piav qhia
1050 aluminium ntawvbelongs rau lub1000 series lag luam ntshiab aluminium alloys. Raws li kev cai lij choj thoob ntiaj teb alloy naming, ob tus lej kawg "50" qhia tias cov ntsiab lus txhuas yuav tsum ncav cuag99.50% los yog siab dua.
Qhov kev xav tau no qhia meej meej hauvTuam Tshoj tus GB / T 3880-2012 tus qauv, uas stipulates tias1050 txhuas yuav tsum muaj tsawg kawg yog 99.5% txhuaskom suav hais tias tsim nyog.
Vim1050 txhuas phaj tsis muaj cov ntsiab lus tseem ceeb alloying, nws cov txheej txheem ntau lawm yog qhov yooj yim, ua rautus nqi tsim khoom qis duathiabmuaj kev lag luam siab. Vim li no,1050 txhuas ntawv yog ib qho ntawm feem ntau siv txhuas alloys hauv kev lag luam.
1050 Aluminium Sheet Cov yam ntxwv tseem ceeb
Industrial ntshiab aluminium xws li1050 aluminium phajyog characterized los ntawm:
Zoo heev plasticity thiab formability
Superior corrosion kuj
High hluav taws xob thiab thermal conductivity
Tsawg ceev (2.71 g / cm³)
Tsawg mechanical zog
Tsis kub- kho tau
Cov yam ntxwv no ua1050 aluminium ntawv thiab sawbzoo tagnrho rau daim ntawv thov qhov twgformability thiab corrosion kujtseem ceeb tshaj lub zog.
1050 Aluminium Sheet Specifications los ntawm GNEE
1050 Aluminium Sheet General Specifications
| Yam khoom | Specification |
|---|---|
| Aluminium Alloy | 1050 |
| Sib npaug Cov Qauv | AA1050, A1050, 1050A, Al99.5 |
| Kub | O, H12, H14, H16, H18, H19, H24, H26 |
| Hardness | 20 HB – 35 HB |
| Cov qauv | GB/T 3880-2012, ASTM B209, 1 |
| Thickness | 0.30-12.00 hli |
| Dav | 800-2600 hli |
| Ntev | 800-11,000 hli |
| Thickness kam rau ua | ± 0.02 hli |
| Dav Tolerance | ± 2 hli |
Daim ntawv muaj:
1050 txhuas ntawv, phaj, sawb, kauj, txhuas vaj huam sib luag, txhuas disc
1050 Aluminium Sheet Chemical Composition Table
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Al |
|---|---|---|---|---|---|---|---|---|---|---|
| 1050 | 0.25 | 0.40 | 0.05 | 0.05 | 0.05 | – | – | 0.05 | 0.03 | Ntau dua lossis sib npaug rau 99.5 |
1050 Aluminium Sheet Mechanical Properties los ntawm Temper
| Kub | Tensile zog (MPa) | Elongation (%) | Dimensional Tswj | Nto Zoo |
|---|---|---|---|---|
| 1050-O | 78MPa ua | Ntau dua lossis sib npaug li 35 | Tsim nyog | Tsim nyog |
| 1050-H12 | 95 MPa ua | Ntau dua lossis sib npaug li 18 | Tsim nyog | Tsim nyog |
| 1050-H14 / H24 | 123 MPa rau | Ntau dua lossis sib npaug 7 | Tsim nyog | Tsim nyog |
| 1050-H18 | 140 MPa | Ntau dua lossis sib npaug 4 | Tsim nyog | Tsim nyog |
1050 Aluminium Sheet Lub cev muaj zog
| Khoom | Tus nqi |
|---|---|
| Qhov ntom | 2.71 g / cm³ |
| Melting Point | 640 degree |
| Modulus ntawm Elasticity | 73gp ua |
| Thermal conductivity | 121 – 193 W/m·K |
| Thermal Expansion | 21.1 ×10⁻⁶ /K |
| Hluav taws xob conductivity |
~ 61% IAB
|
1050 H14 Aluminium Sheet Qhov Zoo & Nta
1050 H14 txhuas ntawv thiab phajmuab cov txiaj ntsig hauv qab no:
Zoo heev formability thiab weldability
Siab plasticity
Zoo heev hluav taws xob thiab thermal conductivity
Tsawg ceev thiab lub teeb yuag
Haum rau roj vuam, TIG vuam, thiab qhov chaw vuam
Muaj zog corrosion kuj
Yuav ua li cas rau hauv1050 txhuas phaj, sawb, coil, thiab ntawv
Tsis tuaj yeem muaj zog los ntawm kev kho cua sov
Daim ntawv thov ntawm 1050 Aluminium Sheet thiab Phaj
Vim nws qhov kev ua tau zoo sib npaug,1050 aluminium ntawv thiab sawbyog dav siv nyob rau hauv daim ntawv thov xav tausiab corrosion kuj thiab zoo formability, mastsis siab zog, xws li:
Cov khoom siv tshuaj thiab cov thawv ntim khoom
Cov paib tsheb thiab txoj kev
Lub tsev facade signage
Chav ua noj thiab cookware
Aluminium ntxuam hniav
Teeb pom kev zoo fixtures thiab reflectors
Xim-coated aluminium ntawv
Kho kom zoo nkauj panels
Kub dab dej
Teeb, npe, thiab cov khoom siv hluav taws xob
Stamping thiab tsim qhov chaw
1050 Aluminium Sheet Nqe Txheej txheem cej luam
Vim1050 aluminium alloy tsis muaj cov ntsiab lus alloying ntxivthiab yuav tsum muaj cov txheej txheem tsim khoom yooj yim, nws tseem nyobib qho ntawm cov nqi ntau tshaj -cov ntawv txhuas zoo hauv khw.
Hom siv tus nqi ntau:
USD 2.3 - 2.7 ib kg(nyob ntawm thickness, temper, thiab kev lag luam tej yam kev mob)
Yuav ua li cas tiv thaiv Oxidation ntawm 1050 Aluminium Sheet
Txawm tias1050 txhuas muaj zoo heev corrosion kuj, tsis tsim nyog cia yuav ua rau oxidation nto los yog pom. GNEE pom zoo cov kev coj ua hauv qab no:
Khaws cov ntawv txhuas hauv aqhuav, huv si, thiab zoo - qhov cua nyob ib puag ncig
Tsis txhob raug los nag, daus, thiab condensation
Tswj dov roj cov dej hauv qab no0.4%
Sivkaw ntim nrog desiccant
Tsis txhob qhib cov ntim ntim tam sim ntawd thaum tsiv los ntawm qhov txias mus rau qhov kub, qhov chaw ntub dej
Ntoo ntim cov dej noo tsawg dua lossis sib npaug li 18%
Aluminium coil kub tsawg dua los yog sib npaug li 45 degree
1050 Aluminium Sheet vs 1060 Aluminium Sheet
| Cov khoom sib piv | 1050 Aluminium | 1060 Aluminium |
|---|---|---|
| Aluminium Cov ntsiab lus | Ntau dua lossis sib npaug li 99.50% | Ntau dua lossis sib npaug li 99.60% |
| Khoom Softness | Ib qho nyuaj dua | Me ntsis softer |
| Kev kho cua sov | Tsis kub- kho tau | Tsis kub- kho tau |
| Kev siv yam | Kev tsim qauv | Sib sib zog nqus nqus & ncab |
Qhov sib txawv yog tsawg, tab sis1060 txhuas yog me ntsis purer thiab ntau haum rau sib sib zog nqus- daim ntaub ntawv kos duab.
1050 Aluminium Sheet vs 5052 Aluminium Phaj
| Yam khoom | 1050 Aluminium | 5052 Aluminium |
|---|---|---|
| Hom alloy | Ntshiab aluminium | Al-Mg alloy |
| Aluminium Cov ntsiab lus | ~99.5% | ~95% |
| Lub zog | Tsawg | Siab |
| Corrosion Resistance | Zoo heev | Zoo heev (qib marine) |
| Yam Nqe | qis | Siab dua (~ USD 250 / tuj ntau) |
5052 aluminium ntawvyog nyiam rau marine thiab structural daim ntaub ntawv, thaum1050 aluminium phajtseem zoo tagnrho rau tus nqi-sensitive, tsis yog- siv cov qauv.
1050 H14 vs 1050 H24 Aluminium Sheet
| Yam khoom | H14 | H24 |
|---|---|---|
| Kev ua haujlwm | Txias yob nkaus xwb | Txias dov + ib nrab annealing |
| Lub zog | Ib yam | Ib yam |
| Elongation | qis | Siab dua |
| Formability | Nruab nrab | Zoo dua |
H24 muaj kev txhim kho ductility piv rau H14 thaum tuav lub zog zoo sib xws.
Summary - Vim Li Cas Xaiv GNEE 1050 Aluminium Sheet
1050 aluminium ntawvyog ib qho ntawmfeem ntau siv cov ntshiab aluminium qibua tsaug rau nws:
ruaj khov zoo
Zoo heev corrosion kuj
Zoo formability
Tus nqi sib tw
Thaum muab khoom1050 txhuas phaj los ntawm Tuam Tshoj, ib txwm thov aMill Test Certificate (MTC)los yogcov ntaub ntawv cov ntaub ntawvlos xyuas kom meej cov ntsiab lus txhuas ntau dua lossis sib npaug li 99.5% thiab qhov zoo ntawm qhov zoo.
Tau txais daim ntawv sib tw rau 1050 Aluminium Sheet los ntawm GNEE
Yog koj tab tom nrhiavsiab -zoo 1050 txhuas ntawv, phaj, sawb, los yog coil,
hu rau GNEE hnub norau kev txhawb nqa, nqi, thiab xa khoom sai thoob ntiaj teb.
