Xaiv 1050 H14 lossis 1050 H18 Txhuas nrog GNEE
Xaiv txoj cai aluminium temper yog ib qho tseem ceeb rau kev ua tau zoo thiab tus nqi efficiency.GNEEkhoom premium1050 H14 Aluminium thiab 1050 H18 Aluminiumnrog ruaj khov zoo, meej tolerances, thiab xa thoob ntiaj teb. Hu rau GNEE hnub no kom tau txais cov kws tshaj lij kev taw qhia thiab cov lus hais nrawm.
1050 H14 Aluminium vs 1050 H18 Txhuas Txheej Txheem
1050 H14 Aluminiumthiab1050 H18 Aluminiumyog temper variants ntawm tib lub siab -purity aluminium alloy muaj kwv yees li 99.5% txhuas. Thaum lawv cov tshuaj lom neeg muaj pes tsawg leeg thiab cov yam ntxwv ntawm lub cev tseem zoo ib yam, qhov sib txawv ntawm qhov txias txias - ua haujlwm hnyav ua rau muaj tus cwj pwm txawv txawv.
1050 H14 Aluminium: Ib nrab -nqus temper nrog superior ductility thiab formability
1050 H18 Aluminium: Puv -nqus siab nrog siab zog thiab hardness
Cov kev sib txawv no cuam tshuam ncaj qha rau kev ua cov txheej txheem thiab xaus - siv cov ntawv thov.
Aluminium 1050 alloy muaj pes tsawg leeg
| Element | Cov ntsiab lus (%) |
| Aluminium (Al) | 99.5-100 Nws |
| Hlau (Fe) | 0 rau 0.4 |
| Silicon (Si) | 0 rau 0.25 |
| Manganese (Mn) | 0 rau 0.050 |
| Zinc (Zn) | 0 rau 0.050 |
| Copper (Cu) | 0 rau 0.050 |
| Magnesium (Mg) | 0 rau 0.050 |
| Vanadium (V) | 0 rau 0.050 |
| Titanium (Ti) | 0 rau 0.030 |
Lub ntsiab sib txawv ntawm 1050 H14 Aluminium thiab 1050 H18 Aluminium
| Yam khoom | 1050 H14 Aluminium | 1050 H18 Aluminium |
|---|---|---|
| Tensile zog | Nruab nrab | Siab dua |
| Yield zog | Nruab nrab | Siab dua |
| Elongation ntawm Break | Siab dua ductility | Tsawg ductility |
| Shear Strength | qis | Siab dua |
| Elastic Performance | Lub zog nqus tau zoo dua | Zoo dua rigidity |
1050 H14 Aluminium vs 1050 H18 Aluminium Daim ntawv thov sib piv
Ob leeg tempers muaj ntau yam, tab sis txhua tus ua tau zoo hauv kev ua haujlwm sib txawv.
| Daim ntawv thov Focus | Pom zoo Alloy |
|---|---|
| Sib sib zog nqus kos duab thiab khoov | 1050 H14 Aluminium |
| Siab load los yog shear kuj | 1050 H18 Aluminium |
| Kev sib sau ua ke | 1050 H14 Aluminium |
| Cov qauv rigidity | 1050 H18 Aluminium |
1050 H14 Aluminium Daim Ntawv Thov
Ua tsaug rau nws zoo heev ductility, corrosion kuj, thiab yooj yim ntawm kev tsim,1050 H14 Aluminiumyog dav siv nyob rau hauv:
- Sib sib zog nqus- rub cov thawv thiab cov khoom tsim
- Cov ntawv vov tsev, phab ntsa panels, thiab cov khoom siv kho kom zoo nkauj
- Thaum tshav kub kub exchangers thiab thermal hloov Cheebtsam
- Cov khoom ntim khoom noj thiab dej haus, suav nrog cov ntawv ci thiab tuaj yeem ua lub cev
1050 H18 Aluminium Daim Ntawv Thov
Nrog nce lub zog thiab shear kuj,1050 H18 Aluminiumyog zoo suited rau:
- Structure framing thiab cov khoom siv ntxiv
- Automotive thiab aerospace panels xav tau ntau dua rigidity
- Hluav taws xob thiab thermal systems xav tau txhua yam kev ruaj ntseg
- Industrial brackets, kev txhawb nqa, thiab thauj khoom -cov kabmob
1050 H14 Aluminium vs 1050 H18 Aluminium Mechanical Properties
| Khoom | 1050 H14 Aluminium | 1050 H18 Aluminium |
|---|---|---|
| Young's Modulus (× 10⁶ psi) | 9.9 | 9.9 |
| Elongation ntawm Break (%) | 8.4 | 4.6 |
| Kev qaug zog (× 10³ psi) | 7.1 | 6.9 |
| Poisson tus ratio | 0.33 | 0.33 |
| Shear Modulus (× 10⁶ psi) | 3.7 | 3.7 |
| Shear zog (× 10³ psi) | 10 | 12 |
| Qhov kawg Tensile Strength (× 10³ psi) | 16 | 20 |
| Yield zog (× 10³ psi) | 14 | 18 |
1050 H14 Aluminium vs 1050 H18 Aluminium Thermal Properties
| Khoom | 1050 H14 Aluminium | 1050 H18 Aluminium |
|---|---|---|
| Latent Kub ntawm Fusion (J / g) | 400 | 400 |
| Max Mechanical Kub (degree F) | 340 | 340 |
| Melting Point (° F) | 1190 | 1190 |
| Thaum tshav kub kub tshwj xeeb (BTU/lb-℃F) | 0.22 | 0.22 |
| Thermal conductivity (BTU/h{0}}ft-℃F) | 130 | 130 |
| Thermal Expansion (µm/m-K) | 24 | 24 |
1050 H14 Aluminium vs 1050 H18 Aluminium Hluav Taws Xob
| Khoom | 1050 H14 Aluminium | 1050 H18 Aluminium |
|---|---|---|
| Hluav taws xob conductivity (Volume, % IACS) | 61 | 61 |
| Hluav taws xob conductivity (qhov hnyav, % IACS) | 200 | 200 |
1050 H14 Aluminium vs 1050 H18 Aluminium Ntxiv Kev Ntsuas Kev Ntsuas
| Khoom | 1050 H14 Aluminium | 1050 H18 Aluminium |
|---|---|---|
| Qhov ceev (lb/ft³) | 170 | 170 |
| Lub zog - rau - Nyhav (Axial) | 11 | 14 |
| Lub zog-rau- Nyhav (Bending) | 19 | 22 |
| Thermal diffusivity (mm² / s) | 94 | 94 |
| Thermal Shock Resistance | 4.8 | 6.2 |
Vim li cas thiaj xaiv GNEE rau 1050 H14 thiab 1050 H18 Txhuas
GNEEkhoom siv1050 H14 Aluminium thiab 1050 H18 Aluminiumhauv cov ntawv, coils, daim hlau, thiab kev cai- txiav cov qauv, txhawb nqa los ntawm kev tswj xyuas nruj thiab txhim khu kev qha logistics. Txawm hais tias koj qhov project tseem ceeb rau kev tsim kho lossis lub zog, peb pab pawg kws tshaj lij xyuas kom koj tau txais cov tshuaj txhuas zoo tshaj plaws.
Hu rau GNEE tam sim nothov ib daim ntawv tsocai, daim ntawv qhia kev, lossis cov kws tshaj lij pom zoo rau koj daim ntawv thov 1050 txhuas.
